A true roll-up garage door coils a curtain above the opening. A sectional door lifts hinged panels onto overhead tracks. Both may be called "roll-up," but they need different hardware and clearance. A coiling door frees ceiling depth while still needing space above the opening for its coil.
Three constructions to distinguish
| Type | How it opens | Typical decision |
|---|---|---|
| Residential sectional | Hinged sections follow ceiling tracks. | Home styling, windows and insulated section choices. |
| Roll-up sheet door | A corrugated sheet curtain coils above the opening. | Storage or utility openings; check security and insulation needs. |
| Rolling service door | Interlocking slats coil around a barrel. | Commercial use with a specified operating frequency and construction. |
A sheet curtain and an interlocking-slat curtain are different products. See Wayne Dalton's sheet-door example and our steel roll-up guide.
Measure clearance before choosing
Record opening width and height, headroom for the coil or hood, side room for guides and operator, and the supporting structure. Less ceiling track does not mean less headroom. Have the installer check the selected door's drawing against the opening.
Operation, cost and upkeep
Manual, chain-hoist and powered operation depend on the model and size. Ask for the operating method, cycle rating, seals, insulation and installed scope. Price and required maintenance differ between basic storage doors and commercial service doors; neither is defined by steel alone.
Installation and spring or barrel repairs require a trained technician. Do not adjust tension or force a curtain that is binding in its guides.
1A Garage Doors gives free estimates on new doors in the Sacramento area. Call (916) 838-8182 or see garage door installation.
